Bus terminal 2 kênh relay output 230VAC 5A Beckhoff KL2602-0010

Technical data	KL2602-0010, KS2602-0010
Connection technology	relay output
Number of outputs	2 x make contacts for power contact
Nominal voltage	230 V AC/30 V DC
Load type	ohmic, inductive, capacitive
Switching current	5 A AC/DC per channel
Inductive switching current	2 A AC/DC per channel
Minimum permitted load	0.1 mA at 0.1 V DC
Electrical isolation	500 V (K-bus/field potential)
Current consumption power contacts	load-dependent
Current consumption K-bus	typ. 80 mA
Bit width in the process image	2 outputs
Operating cycles mech. (min.)	2 x 107
Operating cycles electr. (min.)	8 x 104 (5 A/30 V DC or 5 A/250 V AC and ohmic load)
Configuration	no address or configuration setting
Special features	soft switching at zero voltage crossing significantly extends service life with AC voltage supply
Weight	approx. 85 g
Operating/storage temperature	0…+55 °C/-25…+85 °C
Relative humidity	95 %, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. class/installation pos.	IP 20/variable
Pluggable wiring	for all KSxxxx Bus Terminals
Approvals/markings	CE, UL

Thông tin bổ sung

Thương hiệu	Beckhoff
Thời gian bảo hành	1 Năm
