PLC Keyence KV-3000
Nhiều người mua

PLC Keyence KV-3000

6.500.000 ₫

Khối CPU: sẵn có 24 điểm vào/ra
SKU: KV-3000
Hãng sản xuất: Keyence
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: hóa đơn VAT

Dịch vụ kèm theo:
✓ Lập trình & Sửa chữa PLC Keyence theo yêu cầu
✓ Lắp đặt & vận hành tận nơi
✓ Hỗ trợ kỹ thuật trọn đời
cam kết bán hàng giá tốt
Báo giá
Mã: kv-3000 Danh mục: , Thẻ:
ModelKV-3000
TypeCPU Unit
General Specifications
Power Supply Voltage24 VDC (±10%)
Operating Ambient Temperature0 to 50 °C (no freezing)*1*2
Relative Humidity10 to 95 % RH (no condensation)*1
Altitude-20 to +70 °C*1
Operating EnvironmentBest in environments with minimal dust and corrosive gases
Maximum Altitude2000 m
Noise ImmunityVp-p 1,500 or more, pulse width 1 µs, 50 ns (based on noise simulation), Complies with IEC standards (IEC61000-4-2/3/4/6)
Withstand Voltage1,500 VAC for 1 minute between power terminals and I/O terminals or terminals and auxiliary cover
Insulation ResistanceAbove 50 MΩ (measured between power terminals and I/O terminals or external terminals and cover with a 500 V DC megohmmeter)
Overvoltage CategoryII (When using KV-U7)
Pollution Degree2
Shock and Vibration Resistance
Intermittent Vibration Frequency 5 to 9 Hz: Half amplitude 3.5 mm*3
Frequency 9 to 150 Hz: Acceleration 9.8 m/s2*3
Continuous Vibration Frequency 5 to 9 Hz: Half amplitude 1.75 mm*3
Frequency 9 to 150 Hz: Acceleration 4.9 m/s2*3
Performance Specifications
Control ModeStored Program Mode
I/O Control ModeRefresh Mode
Programming LanguageExtended Ladder Diagram, KV Instructions, Easy-to-remember Symbols
Number of Instructions Basic Instructions: 81 classes, 171 instructions
Application Instructions: 43 classes, 60 instructions
Mathematical Operation Instructions: 115 classes, 293 instructions
Extension Instructions: 96 classes, 142 instructions
Total: 335 classes, 666 instructions
Instruction Execution Speed Basic Instructions: Minimum 10 ns
Application Instructions: Minimum 20 ns
Program CapacityApproximately 160 k steps
Maximum Number of Mountable Units16 units (48 units when connecting expansion units)
Maximum Number of I/O PointsUp to 3,096 points with expansion (KV-EB1S/KV-EB1R: when expanding 2 units, using 64-point I/O units)
Bit Devices
Input Relay RTotal 16,000 points (1 bit)
Output Relay RTotal 16,000 points (1 bit)
Internal Relay RTotal 16,000 points (1 bit)
Link Relay BTotal 16,384 points (1 bit)
Internal Relay MRTotal 16,000 points (1 bit)
Latch Relay LRTotal 16,000 points (1 bit)
Control Relay CR640 points (1 bit)
Word Devices
Timer T4,000 points (32 bit)
Counter C4,000 points (32 bit)
Data Memory DM65,535 points (16 bit)
Extended Data Memory EM65,535 points (16 bit)
File Register Bank Memory FM: 32,768 points × 4 banks (16 bit)
ZF Mode: 131,072 points (16 bit)
Link Register WTotal 16,384 points (16 bit)
Temporary Memory TM512 points (16 bit)
High-Speed Counter CTH2 points (32 bit)
High-Speed Counter Comparator CTC4 points (32 bit, adopts 2 high-speed counters)
Index Register Z12 points (32 bit)
Control Memory CM6,000 points (16 bit)
Output Pulse Positioning2 points (maximum output frequency 100 kHz)
CPU Unit I/OInput: 16 points, Output: 8 points
Power Failure Retention Function
Program MemoryFlash memory, writable up to 100,000 times
Devices5-year battery backup (at 25 °C ambient temperature, in power failure retention mode)*4
Performance Specifications
Self-Diagnostic FunctionCPU abnormality, RAM abnormality, others
Internal Current Consumption CPU Unit: 320 mA or less
Expansion Unit: KV-EB1S 15 mA or less, KV-EB1R 25 mA or less (excluding drive current for input circuits)
Weight CPU Unit: Approximately 300 g
Terminal Block: Approximately 30 g
Starter Block for KV-5500/5000/3000: Approximately 20 g
Expansion Unit: KV-EB1S Approximately 90 g, KV-EB1R Approximately 115 g
*1 Range in which the system can be used.
*2 Based on the temperature at the bottom of the units in the control panel.
*3 According to JIS B 3502 IEC61131-2, Scanning: 10 times in X/Y/Z directions (within 100 minutes).
*4 Target devices: R/LR/CR/T/C/DM/EM/FM/CTH/CTC/CM.

Catalog-plc-keyence-kv-5000

Lựa chọn PLC phù hợp với Module keyence

SKUMô tả
CPU
KV-X500CPU unit
KV-8000CPU unit
KV-7500CPU unit with built-in EtherNet/IP® port
KV-7300CPU unit with built-in serial port
KV-5500CPU unit with built-in EtherNet/IP® port
KV-5000CPU unit with built-in Ethernet port
KV-3000CPU unit with built-in serial port
KV-1000CPU unit with built-in serial port
KV-700CPU unit with built-in serial port
I/O unit
KV-B16RA16-point Screw Terminal Block, Relay Output
KV-B16RC16-point Screw Terminal Block, Relay Output
KV-B16TA16-point Screw Terminal Block, Transistor (Sink)
KV-B16TC16-point Screw Terminal Block, Transistor (Sink)
KV-B16TCP16-point Screw Terminal Block, Transistor (Source)
KV-B16TD16-point Screw Terminal Block, MOSFET (Sink) with Overcurrent Protection
KV-B16XA16-point Screw Terminal Block
KV-B16XC16-point Screw Terminal Block
KV-B8RC8-point Screw Terminal Block, Relay Output (Independent Common)
KV-B8XTD8-point/8-point Screw Terminal Block, MOSFET (Sink), with Overcurrent Protection
KV-C16XTD16-point/16-point Connector MOSFET (Sink) with Overcurrent Protection
KV-C32TA32-point Connector Transistor (Sink)
KV-C32TC32-point Connector Transistor (Sink)
KV-C32TCP32-point Connector Transistor (Source)
KV-C32TD32-point Connector MOSFET (Sink) with Overcurrent Protection
KV-C32XA32-point Connector
KV-C32XC32-point Connector
KV-C32XTD32-point/32-point Connector MOSFET (Sink) with Overcurrent Protection
KV-C64TA64-point Connector Transistor (Sink)
KV-C64TC64-point Connector Transistor (Sink)
KV-C64TCP64-point Connector Transistor (Source)
KV-C64TD64-point Connector MOSFET (Sink) with Overcurrent Protection
KV-C64XA64-point Connector
KV-C64XB64-point Connector, with All Terminals Supporting 2-wire Sensors
KV-C64XC64-point Connector
KV-SIR32XTHigh speed I/O unit
I/O unit/Remote I/O unit
KV-N16ERExpansion output unit, output 16 points, relay output, screw terminal block
KV-N16ETExpansion output unit 16 Outputs Transistor (Sink) Output Screw Terminal Block,
KV-N16ETPExpansion output unit 16-output Transistor (source) output Screw terminal block
KV-N16EXExpansion unit, Input, 16 points, 5/24 VDC switchable, screw terminal block
KV-N8ERExpansion output unit, output 8 points, relay output, screw terminal block
KV-N8ETExpansion output unit 8 Outputs Transistor (Sink) Output Screw Terminal Block,
KV-N8ETPExpansion output unit 8-output Transistor (source) output Screw terminal block
KV-N8EXExpansion Input Unit DC Input 8 Points Type Screw Terminal Block
KV-N8EXRExpansion I/O Unit 16 Points Type Screw Terminal Block, Input(8 Points) relay output(8 Points)
KV-N8EXTExpansion I/O Unit Screw Terminal Block, Screw Terminal Block, Input(8 Points) Transistor (sink)(8 Points)
KV-NC16ETExpansion Output Unit 16-output Transistor (Sink) connector type
KV-NC16ETEExpansion output unit 16 outputs transistor (sink) output European terminal block
KV-NC16ETPExpansion output unit 16-output Transistor (source) output Connector type
KV-NC16ETPEExpansion output unit 16 outputs transistor (source) output European terminal block
KV-NC16EXExpansion Input Unit 16-input switching 5V/24V DC connector type
KV-NC16EXEExpansion input unit input 16 points European terminal block
KV-NC16EXTExpansion I/O unit 32-point connector type 16-input, 16-output (transistor)
KV-NC32ETExpansion Output Unit 32-output Transistor (Sink) connector type
KV-NC32ETPExpansion output unit 32-output Transistor (source) output Connector type
KV-NC32EXExpansion Input Unit 32-input switching 5V/24V DC connector type
KV-NC32EXTExpansion I/O unit 32-input 32-output Transistor (sink) output Connector type
KV-NC8ERExpansion Output Unit 8-output Relay connector type
Analog/Temperature unit
KV-AD40A/D Conversion Unit, 4 Analog Input Channels
KV-AD40GHigh-precision A/D Conversion Unit, 4 Analog Input Channels
KV-AD40VA/D Conversion Unit, 4 Analog Input Channels
KV-AM40VA/D D/A Conversion Unit, 2 Analog Input Channels + 2 Analog Output Channels
KV-DA40D/A Conversion Unit, 4 Analog Output Channels
KV-DA40VD/A Conversion Unit, 4 Analog Output Channels
KV-SAD04High-speed analogue input unit
KV-SDA04High-speed analogue output unit
KV-TF40PID Temperature Adjustment Unit (Multi-input 4-channel)
KV-TP40Temperature Analog Multi-input Unit (Multi-input 4-channel)
Analog/Temperature unit/Remote I/O unit
KV-N3AMAnalog I/O Unit, voltage and current Input 2ch, voltage and current Output 1ch
KV-NC2DAD/A conversion unit (2 points)
KV-NC4ADA/D Conversion Unit 4-point type
KV-NC4TPTemperature 4-input unit
Remote I/O unit
KL-16BR16-point Screw Terminal Block, Relay Output
KL-16BT16-point Screw Terminal Block, Transistor (Sink)
KL-16BX16-point Screw Terminal Block
KL-16CT16-point Connector Transistor (Sink)
KL-16CX16-point Connector
KL-2DAD/A Conversion Unit, 2 Analog Output Channels
KL-2TFPID Temperature Adjustment Unit (2-channel)
KL-32CT32-point Connector Transistor (Sink)
KL-32CX32-point Connector
KL-4ADA/D Conversion Unit, 4 Analog Input Channels
KL-8BLR8-point Screw Terminal Block, Relay Output with Repeater Function
KL-8BLT8-point Screw Terminal Block, Transistor (Sink) Output, with Repeater Function
KL-8BLX8-point Screw Terminal Block with Repeater Function
KL-8BXR8 Input + 8 Relay Output Screw Terminal Block
KL-8BXT8 Input + 8 Transistor (Sink) Output Screw Terminal Block
KL-B1Joint Cable Adapter
KL-DC1ADC Current Input Unit
KL-DC1VDC Voltage Input Unit
KL-LC1Load Cell Measurement Unit
KL-N20VKL Master Unit
KL-T1T-shaped Branch Unit
KL-WH1Power Measurement Unit
KV-EP02EtherNet/IP® Compatible Communication Unit
KV-RC16BR16-point Screw Terminal Block, Relay Output, with Repeater Function
KV-RC16BT16-point Screw Terminal Block, Transistor Output, with Repeater Function
KV-RC16BX16-point Screw Terminal Block Input, with Repeater Function
KV-RC16BXT16-input + 16-output Screw Terminal Block, Transistor Output
KV-RC32BT32-point Screw Terminal Block, Transistor Output
KV-RC32BX32-point Screw Terminal Block Input
KV-RC8BXR8-input + 8-output Screw Terminal Block, Relay Output, with Repeater Function
KV-RC8BXT8-input + 8-output Screw Terminal Block, Transistor Output, with Repeater Function
Positioning/Motion unit
KV-H20G2-axis Pulse Train (Linear and Circular Interpolation and Synchronous Operation Possible) with Built-in 2-channel High-speed Counter
KV-H20S2-axis Pulse Train (Linear Interpolation Possible)
KV-H40S4-axis Pulse Train (Linear Interpolation Possible)
KV-MC20V2-axis Pulse Train Positioning Motion Unit
KV-MC40V4-axis Pulse Train Positioning Motion Unit
KV-ML16V16-axis ML 2-compatible Positioning Motion Unit
KV-MX1INC Encoder, 4 Input Channels, 12 Inputs, 12 Outputs, SD Card
KV-SH04PLHigh-Speed Positioning Unit
KV-XH04ML4-Axis Positioning/Motion Unit
KV-XH16ML16-Axis Positioning/Motion Unit
Highspeed counter unit
KV-SC20V2-channel Multi-function High-speed Counter Unit
KV-SSC02High speed counter unit
Information/Network unit
KV-CL20Master/Local Unit
KV-DN20DeviceNet® Unit
KV-EP21VEtherNet/IP® Unit
KV-FL20VFL-net Unit
KV-L20VSerial Communication Unit
KV-L21VSerial Communication Unit
KV-LE20VEthernet Unit
KV-LE21VEthernet Unit
KV-LH20VCommunication Positioning Unit
KV-LM20VHigh-speed Multi-link (Megalink) Unit
KV-LM21VHigh-speed multi-link Unit
KV-XL202Serial communication unit, 2 ports (RS-232C×2)
KV-XL402Serial communication unit, 2 ports (RS-422A/485×2)
KV-XLE02EtherNet unit, 2 ports
Power/Bus connection unit
KV-7000CBus Connection Unit
KV-EB1Extension Unit
KV-N1Conversion unit with connector unit
KV-NC1Conversion unit with terminal block connector
KV-PU1AC Power Supply Unit with Error Output
